Arduino Projects: Water Level Indicator Using Arduino Nano and Ultrasonic Sensor

Robometricschool. - This is one of the microcontroller project circuit to build water level indicator using Arduino and also ultrasonic sensor. This circuit very suitable when you want to indicate the water level this time.

In here we will give you the global description about the project of water level indicator using Arduino Nano and also ultrasonic sensor the last we will allow you to read more this project from original source.

Electronic Design

Arduino Water Level Indicator (Source: Circuitstoday.com)

Component Parts
  • Arduino Nano ---> 2
  • Ultrasonic Sensor HC-SR04 ----> 1
  • RF Transmitter Receiver Pair ASK 433 ----> 1
  • LCD 16x2 ----> 1
  • Preset 10K ----> 1
  • Switch DPDT (PCB Mount) ---->2
  • Battery 9 Volt ----> 2
  • Battery Holder -----> 2

Description

This is Arduino project water level indicator using Arduino Nano and ultrasonic sensor for you in this time. Accordingly Circuitstoday site describe that Wireless Water Level Indicator Using Ultrasonic sensor & Arduino is an amazing and very useful project. The objective of this project is to notify the user the amount of water that is present in the overhead water tank. This project can be further enhanced to control the water level in the tank by turning it ON, when the water level is LOW, and turning it OFF when the water level is HIGH. Thus, the Arduino water level indicator helps in preventing wastage of water in overhead tank. This project is wireless so, it is easy to install and it can work up to 100 meters.

In this project two circuits are used: a transmitter circuit and a receiver circuit. The transmitter circuit makes use of an ultrasonic sensor to measure the water level in terms of distance. This data is sent to the receiver circuit using RF communication. The water level is shown in terms of percentage on a 16×2 LCD module, which is connected to receiver circuit. Read more Here.
